ECS-DCF-101用于Wi-Fi6和6E网络的陶瓷单块带通滤波器
ECS Inc.晶振集团是一家私人控股的全球领先企业,在维护全球日益增长的高可靠性创新频率控制设备需求方面处于领先地位.一流的研究公司和电子设备设计者,是全球领先的15家开发和生产创新频率控制解决方案的石英晶体,贴片晶振,石英晶体振荡器制造商,超过600家.ECS Inc晶振支持劳动力在香港、韩国、韩国、烟台、中国和美国的生产设施和物流中心超过225家.
ECS晶振公司的DCF过滤器系列是着眼于未来而开发的。这些高性能陶瓷单块带通滤波器提供低插入损耗，而不影响性能。 这些滤波器涵盖5235MHz至6525MHz的中心频率，提供180MHz至1200MHz的带宽。该系列尺寸范围为8.6mmx4.6mm至12.8mmx5.3mm，标准工业工作温度为-40°C至+85°C。ECS DCF带通滤波器应成对购买，将覆盖5GHz和6GHz频段，并提供高达50dBm绝对衰减的高端或低端抑制。 这些表面贴装滤波器设计用于Wi-Fi 6和6E三频路由器、通信系统、家庭安全、安全接入点和电信应用。
ECS-DCF-101用于Wi-Fi6和6E网络的陶瓷单块带通滤波器
180 MHz
Part Number
Center Frequency
Frequency Range
Bandwidth
Use
ECS-DCF-101
5235 MHz
5150 - 5330 MHz
Use in Pairs
ECS-DCF-102
5697 MHz
5490 - 5850 MHz
360 MHz
ECS-DCF-103
5665 MHz
5490 - 5840 MHz
350 MHz
Use in Pairs
ECS-DCF-104
5245 MHz
5150 - 5340 MHz
190 MHz
ECS-DCF-105
6520 MHz
5925 - 7125 MHz
1200 MHz
Use in Pairs
ECS-DCF-106
5492 MHz
5150 - 5835 MHz
685 MHz
ECS-DCF-101用于Wi-Fi6和6E网络的陶瓷单块带通滤波器
系列功能:滤波器中心频率范围为5235MHz至6525MHz
滤波器带宽范围为180MHz至1200MHz
工作温度范围为-40°C至+85°C
尺寸范围从8.6x4.6毫米到12.8x5.3毫米
低插入损耗范围为2.5dB至4.5dB
1 W的输入功率损耗
应用：Wi-Fi 6和6E三频路由器，无线通信，家庭安全，安全访问点，远程通信
